Working range of machining range

Machining width

3000 * 1500/4000* 1500
4000* 2000/6000 * 1500
6000 * 2000 /6000 * 2500
8000* 2500

X-Axis travel

1500mm/2000mm/2500mm

Y-Axis travel

3000mm /4000mm/6000mm/8000mm

Z-Axis travel

220mm

Precision

X,Y Positioning accuracy

±0.05mm/m

X,Y Repeated positioning accuracy

±0.02mm/m

Speed

X,Y Axial positioning speed

80m/min

X,Y Axis acceleration

1.0G

Weight and size

Table load

700kg

Machine weight

About2200kg

Overall dimension (length * width * height)

4600mm*2460mm*1360m
